EH-300S
The EH-300S is a high-performance hot runner controller that is specifically designed for use in a wide variety of industries. This controller features advanced technology and intuitive controls, making it easy to set up and operate. It is capable of controlling up to 24 zones, making it perfect for small to medium-sized hot runner systems. It also has built-in safety features, such as over-temperature protection, to ensure safe and reliable operation.
Configuration:
Specifications:
Operating Power
: 85-250 VAC , 50/60 Hz
Compatible Sensor Type
: J/K Thermocouple
Settable Range
: 0°C - 450°C
Measurement Accuracy
: ±0.25%F.S
Cold- Junction Compensation Accuracy
: ±1°C
Control Mode
: Auto PID or Manual
Control Accuracy
: ±0.1%F.S.
Control Output Device
: Triac
Rated Load
: 15A, 50W~1650W(110V), 100W~3600W(240V)
Operating temperature
: 0°C ~55°C (32 °F ~131 °F )
Operational humidity:
: 10~85%(Non-Condensing)
Storage temperature::
: -20°C ~70°C (-4 °F ~158 °F )
